Ubibot Smart Plug - SP1 WiFi 2.4GHz only Version
Cloud-Supported IoT Remote Control Smart Plug; Big Data Cloud-Based App and Web Platform
- Description
- External Probes & Accessories
- UbiBot Cloud IoT Platform
- Specifications
- Downloads and Documents
UbiBot ® SP1-WiFi is a cloud-supported smart plug that enables full control of connected appliances via WiFi connection according to the environmental conditions. The smart plug supports physical control (via button), user-operated remote control (via App), and fully automatic schedule.
Smart Plug SP1-WiFi can make ordinary appliances connected to the Internet of Things and become intelligent. Smart Plug SP1 can be connected to UbiBot ® IoT Platform. The working status, timing and linkage of other connected devices can be set on the platform to achieve intelligence.
Smart Plug SP1-WiFi can connect a variety of external probes with which it can monitor the environmental conditions and synchronize real-time data to the UbiBot cloud platform using WiFi connection. This allows users access to both real-time and historical data through the UbiBot App or Web Console platform from anywhere in the world. With the automation rules you set, Smart Plug SP1-WiFi can power on/off the appliances connected with it automatically according to the environmental conditions. For example, it can turn on the fan when the temperature is higher than 26 °C. It can also trigger alerts when any metrics go out of the preset range. You will be notified of any actions by free email alerts, app notifications, SMS, voice call, and HTTP.
Features:
- WiFi-enabled wireless remote control and fully automatic control
- New international safety standards - child protection design; 750℃ high temperature flame resistant material
- Scheduling, timer, countdown, and linkage control to automatically power on/off connected appliances
- External probes are supported to realize real-time environmental monitoring and automatic power on/off according to the environmental conditions
- Voltage, Current, Power, Cumulative Electricity Consumption monitoring
- 2.4 GHz WiFi network connection, no hubs or gateways required
- Working with IFTTT, Alexa, Google Assistant, Google Sheet
- Free App & Web Console to access and monitor real-time data remotely, no subscription fee
- Unlimited UbiBot cloud storage for historical data; free historical data export
- Multiple ways of receiving real-time alerts: App notifications, emails, phone calls, SMS, HTTP
- Easy setup with free UbiBot App or PC tools
- With a capacity of 300,000 records, the memory stores all data even if WiFi is temporarily disconnected, ensuring there are no gaps in the data history
- Compliance with CE, FCC, FDA CFR21, IC, RoHS
With splitters, UbiBot® SP1-WiFi supports multiple RS485 probes and 1 x DS18B20-Audio Temperature Probe:
DS18B20-Audio Temperature Probe
TH30S-B Temperature and Humidity Probe
Soil Temperature and Moisture Sensor
PT 100 Industrial-grade Temperature Probe
Wind Speed Sensor
CO2 Probe
NOTE:
- Only 1 of each type of probe can be connected at a time.
| DS18B20 Temperature Probe | More details |
| TH30S-B Air Temperature and Humidity Probe | More details |
| Soil Temperature and Moisture Sensor | More details |
| PT 100 Industrial-grade Temperature Probe | More details |
| Wind Speed Sensor | More details |
| CO2 Probe | More details |
| UbiBot Audio Plug Splitter for connecting external probes | More details |
| UbiBot Audio Splitter - 1 male to 6 females for connecting external probes | More details |
| External Probe Extender - Audio Plug | More details |
UbiBot ® offers a revolutionary way to monitor environmental conditions where they matter. The sensors synchronize data to UbiBot ® IoT Platform using WiFi, Cellular or Ethernet connection (depending on the specific model purchased). Users can then access data from anywhere via a smartphone or the Web console.
Features:
-
Data Management: Manage all your IoT data in one place; you could add as many devices as you want to one UbiBot account.
-
Unlimited Storage: Unlimited cloud-based storage ensures you will never run out of space. This allows you to view all your historical data via UbiBot App or Web.
-
Free App & Web Console: Using UbiBot App and Web Console is free. Powerful and thoughtful features provide you brilliant experience.
-
Analysis and Visualization: Use powerful analysis and visualization tools to get the most out of your data; spot trends and direct comparisons.
-
Real-Time Alerts: Fully customizable alert system will notify you via App notifications, emails, phone call/SMS, HTTP whenever any metric goes out of the range preset.
-
Highly Secure Platform: UbiBot IoT platform is designed to keep all your data secure so you never have to worry about hackers or other security issues.
-
Working with IFTTT, Alexa, Google Assistant, Google Sheet
-
Compliant with FDA CFR21
Details:
Real-time and history data
The UbiBot Platform is a cloud-based IoT platform where all measured data is uploaded and stored. UbiBot App and Web Console allow you to view current data as well as historical data in graphs. The adjustable Y-axis scale allows you to view any tiny fluctuations in the curve.
Customizable alerts and bulk operation
Setting and receiving alerts on your devices helps you to get notified of the conditions timely. When you have many devices to manage, it’s time-consuming to set each alert rule one by one. Therefore, we’ve developed a bulk operation module with which you can set the same rule for many devices at a time.
Free data export
On UbiBot Platform, you can download the history data in CSV or PDF format. The CSV file only contains raw data, while the PDF file is a summarized report with average, maximum and minimum value within the chosen period. The PDF file is much easier to read and archive.
Device sharing and bulk operation
For business users, centralized control over multiple devices is available, with no limit on the number of devices in one account. Also available are bulk operations that apply to sensor settings, alerts, and remote control routines. Devices can be shared with other people, which allows for distributed management by different colleagues.
Intelligent automation in UbiBot platform
UbiBot is committed to building intelligent industrial and home ecosystems. By integrating temperature and humidity sensors and the smart plug SP1 in one system, automated operation is achieved through data linkage. For example, fans can be switched on when the temperature rises to 30 °C.
Data forwarding
UbiBot is an open platform that provides cloud-based services while supporting customers to use their own storage servers. With the data forwarding service, you can forward the data collected by your device to your own private URL to protect privacy.
Location tracking and logging
UbiBot GS1-PL4G1RS is embedded with GNSS (Global navigation satellite system) for positioning. Through mobile data communication, real-time location information is transmitted to the platform and recorded. The UbiBot platform integrates this data, plots it into a trajectory map, and presents it.
Platform-based calibration
UbiBot platform supports data calibration both on the platform level as well as the device level. One-step calibration, instant display, no impact on historical data.
SIM card management
When using UbiBot Global SIM to transfer data, you can manage it by yourself. Unlike other SIM cards with a standard monthly fee and traffic amount, our SIM supports many types of plans. Choose the one that suits you now, and change to another next time. No arrearage and no extra charge.
Technical specifications
| Working Voltage | 100 V - 250 V AC |
| Maximum Current | 16 A |
| Maximum Power | 3.5kW MAX (@220V±10%)/1.7kW MAX (@110V±10%) |
| Power dissipation | ≤0.1 W |
| Measuring Accuracy | ±0.01 A, ±0.1 V, ±0.1 W |
| Working Environment | -10 °C to 60 °C ( 14 °F to 140 °F) |
| Plug Standard | Compatible with Europe, UK, US, France, Australia, Japan, China standards |
Network connection
| WiFi | 2.4GHz or 2.4/5GHz, channels 1-13 (5GHz WiFi NOT supported) |
Physical specifications
| Materials | Flame resistant ABS + PC |
| Dimensions | 65 x 65 x 16.5mm |
| Weight | 50 g (±3 g) | Dimensions | 6.4 x 11.7 x 3.5 cm |
| Color | White |
| Ports | 1 x DS18B20 Audio; 1 x RS485 Audio |
One single pack includes
1 x SP1-WiFi device; 1 x Manual book
| UbiBot SP1 User Guide | More details |
| UbiBot Cloud Platform User Guide | More details |
| UbiBot App User Guide | More details |
| UbiBot PC Tools User Guide | More details |
| UbiBot Cloud Platform Data Forwarding | More details |
| UbiBot On-Premises Platform | More details |
| Using UbiBot with Alexa | More details |
| Using UbiBot with IFTTT | More details |
| Data Sheet |
